High speed price router cnc 3d wooden door engraving carving 1325 CNC router

Brand Name : KC

Model Number : KC1325

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : 5000-7000usd/set

Payment Terms : TT

Supply Ability : 30 SETS PER MONTH

Delivery Time : 10-20days

Packaging Details : plywood box

Contact Now

Wood door engraving carving CNC router

  • Model KC1325
  • Working size: 1300*2500*200mm
  • Functions: Engraving on MDF, solid wood, bone, plastic; cut off wood to produce cabinet, door.
  • Cutting speed 6000mm/min

Model KC1325
Working Area 1300*2500*200mm
Structure,Table Material Heavy duty body
Spindle Motor 4.5kw Italian HSD Air Cooling Spindle
Inverter 5.5KW Taiwan Delta
Rotating Speed of Spindle 18000RPM
Working mode Stepper
Drive mechanism Gear transmission
Linear guide rails Square rails(XY axis :Taiwan Hiwin linear rails and Helical rack and pinion,Z axis:Taiwan Hiwin linear rails and Taiwan Ball Screw)
Lubrication Manual lubrication system
Table Surface Vacuum and T-slot Combined
Motion positioning accuracy ± 0.02/300mm
Repositioning accuracy ± 0.0254mm
Max motion Speed 4,2000mm/min
Max working speed 10,000mm/min
Engraving Tools Ø3.175mm, Ø6mm
Dictate Formate G code, *uoo, *mmg, *plt
Operating voltage AC220V/50~60Hz
Control system DSP control system
Interface USB
Flash Memory 128M
Dust collector Yes
Vacuum pump Water cooling vacuum pump
Soft ware Type3,JDPaint, ArtCAM software
Packing 3.7*2.2*1.8m
Net weight 1400KGS
Gross weight 1500KGS
